SX SC RS SQ Sequence Valve
SUN hydraulic SX SC RS SQ Sequence Valve (2)
SUN hydraulic SX SC RS SQ Sequence Valve (3)

SX SC RS SQ Sequence Valve

SUN hydraulic SX SC RS SQ Sequence Valves yuav muab lub voj voog thib ob nrog ntws thaum lub siab ntawm qhov nkag (chaw nres nkoj 1) tau tshaj qhov chaw valve.

Xa kev nug

Khoom Taw qhia

Khoom Taw Qhia

SUN hydraulic SX SC RS SQ Sequence Valve 2

Txheej txheem cej luam

SUN hydraulic SX SC RS SQ Sequence Valves yuav muab lub voj voog thib ob nrog ntws thaum lub siab ntawm qhov nkag (chaw nres nkoj 1) tau tshaj qhov chaw valve. Kev teeb tsa siab ntawm qhov sib txuas valve tswj lub siab ntawm qhov chaw nres nkoj 1 txheeb ze rau lub siab ntawm qhov ntws (chaw nres nkoj 3). Cov li qub no tsis hnov qab lub siab ntawm qhov chaw nres nkoj 2 (ib ntus), mus txog rau qhov chaw teeb tsa. SUN hydraulic SX SC RS SQ Sequence Valves yuav raug siv los tswj lub siab nyob rau hauv qhov chaw ntawm 2-chaw nres nkoj nyem li qub yog tias muaj siab nyob rau hauv txoj kab rov qab.

Tag nrho 3 chaw nres nkoj SUN hydraulic SX SC RS SQ Sequence Valves yog lub cev thiab ua haujlwm sib hloov tau (piv txwv li tib txoj kev ntws, tib kab noj hniav rau ib qho loj me me).
W thiab Y tswj tau (qhov twg siv tau) tuaj yeem teev nrog lossis tsis muaj qhov tshwj xeeb. Thaum tsis muaj qhov tshwj xeeb tau teev tseg, lub valve tuaj yeem kho tau thoob plaws hauv nws cov khoom siv tag nrho siv W lossis Y tswj. Thaum qhov chaw tshwj xeeb tau teev tseg, qhov teeb tsa no sawv cev rau qhov chaw siab tshaj plaws ntawm lub valve.
Pilot flow tseem nce ntxiv raws li qhov siab ntawm qhov chaw nres nkoj 1 (inlet), txheeb ze rau qhov siab ntawm qhov chaw nres nkoj 3 (drain), nce siab saum lub valve.
Lub ntsiab theem ntawm lub qhov rooj yog tiv thaiv los ntawm 150 micron stainless hlau screen.
Lub siab ntawm qhov chaw nres nkoj 3 yog ncaj qha ntxiv rau lub valve chaw ntawm qhov sib piv 1: 1 thiab yuav tsum tsis pub tshaj 5000 psi (350 bar).
Tsis haum rau siv nyob rau hauv load tuav daim ntaub ntawv vim spool to.
Corrosion resistant cartridge li qub yog npaj rau siv nyob rau hauv corrosive ib puag ncig thiab raug txheeb xyuas los ntawm tus qauv code suffix / AP rau sab nraud stainless hlau Cheebtsam, los yog / LH rau sab nraud zinc-nickel plated Cheebtsam. Saib qhov CONFIGURATION rau txhua qhov kev xaiv. Yog xav paub ntxiv, thov mus saib cov ntaub ntawv ntawm Kev Tsim Kho nplooj ntawv nyob rau hauv TECH RESOURCES.
Koom nrog lub hnub ntab style kev tsim kho kom txo tau qhov muaj peev xwm ntawm cov khoom siv sab hauv khi vim kev teeb tsa ntau dhau torque thiab / lossis kab noj hniav / cartridge machining variations.
